Cousz F-460: Compact, High-Precision UV Measuring Instrument for Real-Time Monitoring

The Cousz F-460 is a state-of-the-art, compact online UV measuring instrument designed to deliver accurate and real-time UV power monitoring for automated production lines. This advanced device is divided into two key components: the body and the sensor, making it highly adaptable for seamless integration into various industrial setups.

With its RS485 communication interface and simple communication protocol, the F-460 offers direct communication with PLCs, computers, and PCs, enabling real-time data acquisition and continuous monitoring. This makes it an invaluable tool for industries that require precise UV measurement and control, ensuring optimal performance and efficiency.

Key Features of the Cousz F-460:

1. Ultra-Compact UV Intelligent Digital Probe: The F-460 is equipped with an ultra-small-sized probe that is not only easy to install but also user-friendly, ensuring hassle-free operation in any industrial environment.
2. Wide DC Power Supply Range: Designed for industrial field use, the F-460 supports a broad DC power supply range, making it versatile and reliable across various applications.
3. RS485 Communication Interface: With the RS485 interface, the F-460 allows seamless integration with other smart devices and systems, providing flexible data connectivity and real-time monitoring capabilities.

Specifications:

• Spectrum Range:
  • UVA (320-390nm) @ 365nm: Ideal for testing 365/385nm UV-LED lamps and traditional UV lamps.
  • UVV (390-445nm) @ 405nm: Designed for testing 395/405nm UV-LED lamps.
  • UVV2 (445-500nm) @ 450nm: Perfect for testing 450nm UV-LED lamps.
• Max Intensity: 20 W/cm²
• Test Accuracy: ±10%
• Measurement Accuracy: 0.01 mW/cm²
• Temperature Range: -55 to 125°C
• Data Acquisition Rate: 10Hz/s
• Power Supply Voltage: DC12V
• Communication Interface: RS485
• Probe Line Length: 1 meter, with a temperature resistance of up to 200°C (Teflon)
• Working Temperature: -40 to 100°C
• Probe Dimensions: L(36mm) * W(18mm) * H(11mm)
• Body Dimensions: L(78mm) * W(36mm) * H(16.5mm)

The Cousz F-460 offers reliable, real-time UV monitoring for any automated system, ensuring precision and efficiency. Its compact size, coupled with powerful features, makes it an ideal solution for industries that rely on accurate UV measurements to maintain optimal product quality and performance.

Discover more about Cousz F-460 today and elevate your UV monitoring capabilities.
